Description
- For quick and easy welding from all sides
- Easy to use
- Simple angle adjustment with a knob
- Infinitely adjustable plate speed with clockwise/anti-clockwise rotation
- Control electronics protected by a robust and enclosed housing
- Foot switch for start/stop
Dimensions and weights
Length (product) approx.
770mm
Width/depth (product) approx.
650mm
Height (product) approx.
660mm
Weight (net) approx.
220kg
Turntable diameter
550mm
Technical data
Drive type
electric
Load capacity Horizontal table position
500kg
Load capacity Vertical table position
250kg
Speed
0 – 5min¯¹
Permissible welding current
300A
Table angle
-45 – 90°
Cable length foot switch
2m
Electrical data
Input power
400W
Supply voltage
230V
Network frequency
50Hz
