Description
We are the official distributor of TELWIN brand. We guarantee the originality of the product, professional advice and service support.
TELWIN ELECTROMIG 330 WAVE: Smart Welding, Professional Power for the Demanding! ✨?
TELWIN ELECTROMIG 330 WAVE 400V + ACC. is more than just a welder – it’s your partner for the most challenging welding projects. Created for professionals who do not accept compromises on quality, performance and versatility, this machine revolutionizes the approach to MIG/MAG, MMA and TIG Lift welding. Forget about equipment limitations and complicated setups. The ELECTROMIG 330 WAVE, with its advanced WAVE OS, opens the door to a world of intelligent welding, where precision goes hand in hand with intuitive operation.
Imagine a device that adapts to your needs, the material and the specifics of the job, always offering optimal performance. This is the essence of WAVE OS technology. It makes even the most complex welding operations, such as working with thin stainless steel sheets, demanding aluminum alloys or brazing galvanized sheets, simpler and more efficient. A synergy system with fully customizable programs and access to advanced arc processes (such as ATC – Advanced Thermal Control, or special curves for Root-MIG) guarantee welds of impeccable quality, minimizing the risk of errors and the need for costly corrections.
The ELECTROMIG 330 WAVE is synonymous with versatility. Whether you’re working on heavy steel structures, precision stainless steel parts or delicate aluminum components, this unit will give you the power and control you need to achieve perfect results. The robust, three-phase (400V) design ensures stable operation even under heavy use in workshop and industrial settings. The included accessories further enhance the convenience and readiness to work right out of the box.
When you invest in the TELWIN ELECTROMIG 330 WAVE, you are investing in the technology of the future that will raise the standards of your work. Not only will it save you time through faster setup and less waste, but most importantly, it will ensure that every weld is a testament to your professionalism. See how Telwin’s intelligent solutions can optimize your welding processes and open up new opportunities for growth. ??️
Explore the Advanced Capabilities of TELWIN ELECTROMIG 330 WAVE 400V + ACC.
Detailed information
The WAVE OS is a true revolution in welder interaction, making the TELWIN ELECTROMIG 330 WAVE an intelligent working tool. This advanced software manages all aspects of the welding process, not only offering a rich library of synergistic programs for a variety of materials (carbon steel, stainless steels, aluminum, CuSi3/CuAl8 brazing) and shielding gases, but also allowing full customization. You can customize arc dynamics, wire heat-up time, gas discharge before and after welding, and then save these settings as your own unique programs, ideally suited to your specific tasks or preferences.
What’s more, WAVE OS is an open system for the future. With the ability to update the software via the USB port, your welder can gain new functionality and improved synergy curves without having to replace the machine. This is a guarantee that the ELECTROMIG 330 WAVE will always be up to date with the latest technological developments from Telwin. For the professional, this means an investment that doesn’t age, and in fact evolves with technology, providing constant access to optimal welding solutions.
Detailed information
TELWIN ELECTROMIG 330 WAVE, with its WAVE OS system, makes available a range of advanced welding processes to achieve masterful weld quality in all conditions. One of the key ones is ATC (Advanced Thermal Control), a technology ideal for welding thin materials (e.g., body sheets <1.5mm). ATC precisely controls the thermal energy of the arc, minimizing the risk of burn-through and distortion, which is extremely important when working with delicate parts.
Special ROOT-MIG programs are available for tasks that require excellent remelting and strong joints, especially at ridge layers. These provide a stable, concentrated arc, making it easier to form a proper weld from the start. Depending on the active version of the WAVE OS software, the welder can also offer advanced pulse (PULSE) and double pulse (PoP – Pulse on Pulse) welding modes. These are indispensable for welding aluminum alloys and stainless steel, where precise control of heat input, minimization of spatter and weld aesthetics are a priority. These features translate into less finishing work, higher structural integrity of joints and the ability to weld materials considered difficult.
Detailed information
The ELECTROMIG 330 WAVE is a truly versatile welding station, designed for maximum flexibility. The primary method is advanced MIG/MAG welding, where, in addition to the manual mode, the full potential is shown by the WAVE OS synergy. The machine is perfect for welding black steel, stainless steel, aluminum (with the right accessories like a dedicated chuck and U-shaped rollers) and for soldering with CuSi3 or CuAl8 wires, which is crucial in the automotive industry for joining galvanized and high-strength sheet metal.
When a project requires covered electrode welding, the ELECTROMIG 330 WAVE seamlessly switches to MMA mode. It offers stable welding current for a wide range of electrodes (rutile, alkaline, cellulose), and the built-in Arc Force (dynamic short-circuit current control), Hot Start (facilitated arc ignition) and Anti-Stick (preventing electrode sticking) functions significantly simplify work and improve weld quality. In addition, the TIG Lift DC function with friction ignition allows precise TIG welding of stainless or carbon steel, which is ideal for tasks requiring high aesthetics and weld cleanliness. Such versatility makes this device indispensable in any professional workshop, eliminating the need for multiple specialized machines.
Technical Specifications
| Parameter | Value |
|---|---|
| Brand | TELWIN |
| Model | ELECTROMIG 330 WAVE 400V + ACC. |
| Full Name | TELWIN ELECTROMIG 330 WAVE 400V + ACC. |
| Catalog number | 816061 |
| EAN code | 8004897926094 |
| Power supply | Three-phase 400V AC (50/60 Hz) |
| MIG/MAG welding current range | 20 – 320 A |
| MMA welding current range | 20 – 300 A |
| TIG Lift welding current range | 20 – 300 A |
| MIG/MAG duty cycle (according to EN60974-1 at 40°C) | |
| Idle voltage | approx. 65 V |
| Rated power (60% / max) | 7 kW / 11 kW |
| Power factor (cos φ) | 0.9 |
| Degree of protection | IP23 |
| Steel wire diameter | 0.6 – 1.2 mm |
| Stainless wire diameter | 0.8 – 1.2 mm |
| Diameter of aluminum wire | 0.8 – 1.2 mm (special holder and rollers recommended) |
| Diameter of core wire (FLUX) | 0.8 – 1.2 mm |
| Wire diameter for soldering (CuSi3, CuAl8) | 0.8 – 1.0 mm |
| Diameter of covered electrodes (MMA) | 1.6 – 6.0 mm |
| Number of feeding rollers | 4 (ensures stable wire feeding) |
| Dimensions (D x S x W) | 860 x 450 x 800 mm (may vary slightly depending on configuration with cart) |
| Weight | approx. 45 kg (without accessories and wire) |
Key Features and Benefits
- ? WAVE OS Intelligent Operating System: This is the heart of the machine, revolutionizing welder-machine interaction. WAVE OS offers advanced synergy programs for a wide range of materials (steel, stainless steel, aluminum, brazing) and shielding gases, automatically selecting the optimal welding parameters. It also allows you to create and save your own personalized programs and easily update the software. For the professional, this means drastically reduced setup time, unmatched repeatability of weld quality, the ability to fine-tune parameters for specific tasks, and access to the latest Telwin welding technologies.
- ? Versatility of Welding Processes (MIG/MAG, MMA, TIG Lift): The ELECTROMIG 330 WAVE is a true multitalent. In addition to advanced MIG/MAG welding (including synergistic, pulsed – if supported by the WAVE on this model, and manual), the unit offers full support for shielded electrode welding (MMA) with Arc Force, Hot Start and Anti-Stick functions, and TIG Lift welding with contact ignition. For the user, that’s the flexibility to perform virtually any welding task with a single machine, saving workshop space, reducing investment costs in separate machines and being ready for a variety of project challenges.
- ⚙️ Advanced Arc Control Features (ATC, ROOT-MIG, optional Puls/PoP): WAVE OS technology integrates specialized features to improve welding quality and efficiency. ATC (Advanced Thermal Control) provides superior control of arc line energy, minimizing thermal distortion when welding thin materials. ROOT-MIG programs facilitate boundary layers and graft welding with excellent fusion. Depending on the WAVE OS configuration, Puls and Pulse-on-Pulse (PoP) modes may also be available, ideal for welding aluminum and stainless steel, reducing heat input and providing aesthetically pleasing welds. Benefits include: less material deformation, higher weld quality with no under or sticking, excellent weld face appearance, and the ability to efficiently weld difficult materials and thin sheets.
- ?️ Color TFT Display and Intuitive User Interface: Navigating the advanced functions of the welder is extremely easy thanks to the large, easy-to-read TFT display and the well-thought-out graphical interface. All parameters are clearly presented and are adjusted in a logical and intuitive manner. For the welder, this means quick adaptation to the operation of the device, minimizing the risk of setting errors, easy access to all functions and full control over the welding process in real time.
- ? Robust Construction and Professional 4-Roll Feeder: Designed for use in demanding industrial environments, the ELECTROMIG 330 WAVE welder features a sturdy housing and high-quality components. A key component is the professional 4-roller wire feeding mechanism, which guarantees smooth and stable feeding of even long and soft wires (e.g., aluminum using the appropriate rollers and guides). For the professional, this ensures reliable operation for many years, minimizes downtime due to breakdowns, and provides precise and uninterrupted wire feeding, which is crucial for weld quality.
Product Application
- ? Manufacturing and installation of medium and heavy steel and aluminum structures.
- ? Advanced locksmith, mechanical and repair workshops.
- ? Professional auto body repairs, including brazing of galvanized sheet metal and HSS (High Strength Steel).
- ? Maintenance and upkeep work in industrial plants.
- ?️ Construction, including welding of rebar and structural components on site (with adequate power supply).
- 船舶 Manufacturing and repairing small vessels, agricultural machinery and specialized vehicles.
- ⚙️ Welding of stainless steel pipelines and tanks in the food, chemical and pharmaceutical industries.
Contents of the Kit
- ? TELWIN ELECTROMIG 330 WAVE 400V welder (816061)
- ?️ Professional MIG/MAG welding chuck (e.g. Telwin MT36 or equivalent, 3m or 4m).
- ? Ground wire with solid clamp
- ⚙️ Wire feed rollers for common diameters (e.g. 0.8/1.0 mm or 1.0/1.2 mm, steel)
- ? Hose for shielding gas connection
- ? Operating instructions and warranty card
- (Note: The exact contents of the accessories “ACC.” may vary depending on the distributor or promotion. Confirmation with the dealer is recommended.)
Summary: TELWIN ELECTROMIG 330 WAVE 400V + ACC. – Your Best Investment
TELWIN ELECTROMIG 330 WAVE 400V + ACC. is more than a welder – it’s your key to achieving welding mastery. With breakthrough WAVE OS technology, unmatched material and process versatility, and rugged construction, you get a tool that meets every challenge. Improve the quality of your work, optimize your processes and gain a competitive edge. Invest in smart welding with Telwin and feel the difference that truly professional equipment makes. Contact us today to learn more and choose the best solution for your workshop! ?
Part number: 816061
EAN code: 8004897926094
