The Böhler URANOS NX 3200 PME is a top-of-the-line welding current source that combines state-of-the-art technology with maximum functionality and reliability. Developed for professionals, this device offers full control over the welding process thanks to a precise power system, intelligent algorithms and a wide range of synergy programs.
Maximum power and versatility
With a welding current of up to 320A and high efficiency (85%), the URANOS NX 3200 PME guarantees excellent weld quality even in the most demanding conditions. The machine handles a wide range of materials, from carbon and stainless steels, duplex steels, aluminum and copper, to hardfacing, making it an ideal choice for industries such as aerospace, shipbuilding, rail, chemical, energy and automotive.
The Böhler URANOS NX 3200 PME supports the full spectrum of welding methods:
- MIG/MAG and Pulsed MIG/MAG – excellent process control, minimized spatter and precise arc stabilization
- TIG DC Lift – reduction of electromagnetic interference, clean arc ignition
- MMA – covered electrode welding with advanced support functions (Hot Start, Arc Force, Anti-Sticking)
Why choose URANOS NX 3200 PME?
- greenWave® inverter technology – optimization of energy consumption and maximum arc stability.
- High operating efficiency – at 40°C the device reaches 320A at 50% duty cycle, and at 25°C as much as 320A at 70%.
- Supports a wide range of wire diameters – from 0.6 mm to 1.6 mm (aluminum, core, steel).
- Integrated 4-roll wire feeder – ensures even wire feeding and precise process control.
- Digital control panel (3.5″ LCD) – intuitive menu, full control over all parameters.
- Synergistic welding programs (600 predefined) – make it easy to select the optimal parameters.
- Ability to save 240 custom configurations – full personalization of settings.
- Function of automatic saving of the last settings – convenient restoration of parameters after a restart.
Innovative technologies for professionals
- CAN fieldbus system – super-fast digital communication for maximum control precision
- Software updated on a regular basis – possibility to extend the functionality of the device
- Full encapsulation of electronics – protection from dust, moisture and contaminants
- Linear controlled fan – works only when necessary, which increases the life of components
- Remote control and Ethernet integration – full control of welding parameters from a computer
- Possibility to connect Push-Pull handle and WU cooler – support for precise wire feeding and extend the life of the machine
Key technical parameters:
Welding current range: 3A – 320A
Duty cycle (MIG/MAG – 40°C):
-
50% – 320A
-
60% – 310A
-
100% – 250A
Duty cycle (MIG/MAG – 25°C):
-
70% – 320A
-
100% – 270A
Wire diameter: 0.6 – 1.6 mm (steel, aluminum, core wire)
Wire feed speed: 0.5 – 22.0 m/min
Wire feeder: 4-roll (2-roll for WF NX 2000 model)
Supply voltage: 3x400V / 3x230V ±15%
Maximum power consumption: 13.3 kVA
Weight: 27.6 kg
The Böhler URANOS NX 3200 PME is a welder designed for the most demanding users. With its advanced technology, intelligent control and wide range of capabilities, it is the ideal choice for industrial plants, workshops, shipyards, as well as the automotive or aerospace industry. With its high power, state-of-the-art greenWave® technology and full digital control, this machine guarantees precision, efficiency and reliability in any situation. If you are looking for a professional and efficient welding machine, the Böhler URANOS NX 3200 PME is the best choice.
Standard set:
Symbol: 55.03.066
