Spartus Maximus 3D welding table 2400x1200x200mm | diagonal | D28 | 6 legs with feet L=650mm

Nitrided SPARTUS MAXIMUS welding table in the D28 system, diagonal grid

The SPARTUS MAXIMUS D28 welding table is an advanced solution for the most demanding machining and welding of steel structures. Made of heavy nitrided S355J2+N steel and fitted with the Ø28 mm fixing system, it gives professional production stations an extremely stable, industrial base. Its high strength, precise workmanship and modular design make it a premium-class tool for specialists who need absolute repeatability and durability.

25 mm nitrided top: maximum durability and resistance

The key feature of the SPARTUS MAXIMUS D28 table is its nitrided top surface, which considerably increases hardness and resistance to abrasion, corrosion and high temperature. Thanks to nitriding, the S355J2+N steel keeps ideal working properties even under the intensive use typical of large-series production and large-scale structures.

A top thickness of 25 mm places the SPARTUS MAXIMUS D28 among the most rugged tables on the market. This design minimises vibration, increases resistance to deformation and keeps the top flat over many years of use.

Reinforced ribbing for maximum rigidity

Under the work surface of SPARTUS MAXIMUS tables there is heavy, precisely designed ribbing that considerably increases the rigidity of the whole structure. Closely spaced ribs eliminate the risk of sagging and deformation and keep the top stable even under heavy loads and when you work with heavy steel parts. The table holds a flatness of 0.1 mm / 1000 mm, which meets strict industrial requirements. This accuracy gives ideal conditions for positioning parts with tight geometric tolerances.

System of drilled and milled Ø28 mm holes

The SPARTUS MAXIMUS D28 table has high-precision Ø28 mm fixing holes, drilled and milled to system accuracy. The hole pattern of the D28 system grid gives full compatibility with accessories designed for heavy structural parts. The D28 system allows:

• fast clamping of heavy and large workpieces,
• stable work with system clamps and fixtures,
• repeatable setups in series production,
• full integration with advanced measuring fixtures and assembly frames.

Millimetre scale

A clearly visible millimetre scale is marked on the table top, so you can position parts, fixtures and accessories quickly. The work becomes more intuitive and a setup takes less time, especially in repetitive and series production.

Diagonal grid: maximum setting precision and control of geometry

The SPARTUS MAXIMUS D28 table in the diagonal grid version considerably extends the options for positioning parts. The diagonal lines let you lay out angles, axes of symmetry and the run of the structure quickly and very accurately. This makes the table well suited to work that calls for precise geometry, such as building frames, spatial segments, bent profiles or tubular structures. The diagonal grid also makes it easier to check deviation and twist, which improves repeatability and reduces the risk of assembly errors. It clearly speeds up work wherever exact alignment and geometry of the parts matter.

Modular 3D side, 200 mm wide

SPARTUS MAXIMUS D28 tables have a modular 3D side 200 mm wide, which lets you build structures in three axes at once. With it you can: enlarge the work surface, clamp parts vertically and at an angle, create dedicated assembly setups and adapt the shape of the table to individual projects. The wide 3D side gives high stability and full compatibility with D28 accessories, and it is one of the key elements of the system for professionals.

Applications of SPARTUS MAXIMUS D28 welding tables

SPARTUS D28 welding tables are key equipment for:

• heavy industry and steel structure fabrication,
• welding and assembly of large components,
• production and assembly lines,
• companies building frames, tanks, vehicles and large-scale structures,
• professional metalworking shops, prototype workshops and training centres.

The D28 system offers top stability and compatibility with accessories that make even the most demanding projects possible.

Tools for SPARTUS D28 welding tables

SPARTUS offers a full line of accessories dedicated to the D28 system:

• system clamps,
• 2D and 3D squares,
• assembly blocks and prisms,
• pins, bolts, stops,
• elements for extending the work surface,
• ready-made accessory sets for different applications.

Full compatibility with the hole system and the 3D side lets you build highly advanced assembly stations that you can adapt to every stage of the production process.

SPARTUS MAXIMUS D28, the standard for professional work

When you choose the SPARTUS MAXIMUS D28 welding table, you invest in precision, stability and durability at an industrial level. It is built for users who expect full stability when working with large structures.
