INDUCTOR DRAGON IHD500 is an induction heater for fast, flameless heating of ferrous metals and aluminium. Power supply 230V. Power 8 kW.
Technical data
INDUCTOR 8 IHD500 is an induction heater for fast, flameless heating of ferrous metals and aluminium.
Using electromagnetic induction, it can deliver a large amount of heat to a precise spot within just a few seconds, to a depth of 5mm. It heats metal to ‘red’ (approx. 1000°C) over an area of 8x13mm and a thickness of 5mm in 1 second. Because it heats only the selected area, it does not damage glass, rubber or plastic parts or painted surfaces close to where the heater is working.
Recommended for every car and van service workshop for bodywork and mechanical repairs. Suitable for overhaul work and wheel alignment, tyre shops and mechanical workshops. It makes it easier to remove seized bolts, nuts, pins, bearings and other car parts.
It shortens repair time and gives you maximum control over heating during work. Unlike a gas torch, the induction heater heats the metal only at the selected spot, to a temperature of 500-600°C, and does not change the technical properties of the steel.
Power adjustable in steps of 10%.
Power supply
Single-phase power supply 230V.
Warranty terms
12-month warranty for professional use. Warranty service is handled door-to-door, with no transport costs for the user. Made in the EU.
Mains current draw
24A (peak)
Mains fuse
25A slow-blow
Rated supply voltage
230V; 50Hz/60Hz (1ph)
Total cable length
3 m
Tank capacity
20 litres
Cooling type
liquid
Protection rating
IP 21
Weight
65kg with coolant
Overall dimensions L x W x H
43x42x104 cm
Continuous operating time
over 30 minutes at maximum power
Frequency
15-50 kHz, adjusted automatically
Continuous power
5.4 kW
Maximum power
8 kW
Heating capacity (temperature approx. 1000°C)
8x13x5mm in 1 second
Adjustment steps
10
