The EXPERT PLASMA 40 KOMPRESSOR is a professional plasma cutting machine. It cuts steel, stainless steel, aluminium, brass and copper without distortion. Electronically controlled, stepless adjustment of the cutting current. The machine works well in the workshop and during work on site.
The cutter has a built in compressor and an external compressed air connection, which lets it work in any conditions.
The machine offers a continuous cutting mode and cutting with the arc held on (for perforated material).
The clear digital display allows accurate setting of the machine, gives stable parameters and high cut quality.
Physical parameters
The machine has fan cooling, which considerably increases its output.
The machine has overload protection, which increases its reliability.
Supply parameters
Single phase supply 230V
The machine comes with a mains plug.
Equipment
The delivery covers the machine with a manual IPT40 plasma torch, 4m, central connector, and an earth cable 3m long.
| Compressed air pressure | 5-6 Bar |
| Cutting thickness (max) | 18 mm (external compressor) / 14 mm (built in compressor) |
| Compressed air output | 200 l/min |
| Cutting current adjustment range | 20 - 40 A |
| PHYSICAL PARAMETERS | |
| Protection degree | IP 23 |
| Weight | 25 kg |
| Overall dimensions l x w x h | 595x220x440 mm |
| Packaging dimensions l x w x h | 710x290x530 mm |
| TECHNICAL PARAMETERS | |
| Power | 4.5 kW |
| Open circuit voltage | 320 V |
| Maximum current | 40 A |
| Current at 60% duty | 40 A |
| SUPPLY PARAMETERS | |
| Mains protection | C25A |
| Rated supply voltage | 230V, 50/60 Hz |
