Description
The device can be used both indoors and outdoors IP 23
Anti-Stick
Hot-Start
Arc Force Control
PFC – power factor correction
VRD – Reduction of idle voltage
Product description
- The device can be used both indoors and outdoors indoors IP 23
- Protection against moisture, salt spray, corrosion by sealed plate, making it suitable for heavy-duty operation
- Hot-Start: increased starting current to make arc ignition easier
- Anti-stick prevents the electrode from sticking to the material
- Arc Force Control: infinitely adjustable arc dynamics – a choice between a soft (diffuse) arc giving a shallower depth of fusion, useful when welding thin sheet metal, and a hard (focused) arc giving a deep fusion into the material.
- Devices equipped with PFC (Power Factor Correction), VRD (Reduction of Idle Voltage)
- TIG DC function = allows easy TIG welding with contact ignition
- Accurate setting of welding parameters with digital display
- Constant welding current ensures consistent melting performance
| Technical data | CRAFT-STICK 161 P |
| Ø of welding electrode | 1.6~3.2 mm |
| Electrode adjustment range | 10~140 A |
| Input voltage 50/60 Hz | 160~275 V |
| Duty cycle at Lmax. at 40 ° C | 30% |
| ED 100% welding current | 90 A |
| Fuse | 16 A |
| Open circuit voltage | 14,5 V |
| ingress protection | IP 23 |
| Dimensions (L x W x H) | 365 x 150 x 280 mm |
| Weight | 6.1 kg |
Scope of delivery:
- Welding cable 3m 16mm² with electrode holder
- Ground wire 3m 16mm² with ground terminal 200A
