We are the official distributor of the TELWIN brand. We guarantee a genuine product, professional advice and service support.
TELWIN TECHNOLOGY 238 XT CE/MPGE: Your Portable Source of Power and Reliability in MMA and TIG Welding.
Imagine a welder that keeps up with you on the most demanding projects and then goes a step further. TELWIN TECHNOLOGY 238 XT CE/MPGE is exactly that machine, built by Italian engineers for professionals who refuse to compromise on quality, output and reliability. Whether you work in rough site conditions on generator power, or handle precise tasks in the workshop, this inverter welder becomes a tool you can count on.
Forget an unstable arc, trouble striking the electrode or equipment that limits what you can take on. TECHNOLOGY 238 XT carries advanced solutions such as the MPGE system (Multi Protection for MotorGenerator), which keeps the machine running even when generator voltage fluctuates. That means peace of mind and the certainty that your work will not stop at the worst possible moment. With 200A of welding current and a high duty cycle, you handle a broad set of materials and thicknesses, from carbon steel through stainless steel to cast iron.
At the heart of the machine sits modern inverter technology, which delivers excellent welding parameters together with compact dimensions and low weight. That is the mobility you need to move quickly between work stations. Smart functions such as Arc Force, Hot Start and Anti-Stick actively support the welding process and make a clean bead easier to achieve every time, also for welders with less experience, while still leaving full control to professionals.
TELWIN TECHNOLOGY 238 XT is more than a welder, it is an investment in efficiency, precision and reliability that pays back quickly. It is a tool that lets you raise the quality of your services, shorten lead times on orders and gain an edge over the competition. See for yourself how welding can become simpler, faster and more satisfying.
Advanced Capabilities of the TELWIN TECHNOLOGY 238 XT CE/MPGE 230V
MPGE: Uninterrupted Power and Protection on Generator Supply
Work in the field often means running from a generator, and generator voltage is not always stable. The MPGE system (Multi Protection for MotorGenerator) in the TELWIN TECHNOLOGY 238 XT welder is an advanced answer to that problem. The machine has multi level protection that actively monitors and compensates input voltage fluctuations, shielding the sensitive inverter electronics from damage.
Thanks to MPGE the welder holds a stable arc and correct welding parameters, and it also copes with voltage surges and undervoltage typical of generator work. For a professional this means reliability in typical workshop conditions, the option to take on jobs in remote locations without mains access, and a clearly longer service life of the machine. It is an investment in calm and continuity of work, whatever the quality of the supply.
Smart Support for the Welder: Arc Force, Hot Start, Anti-Stick
TELWIN TECHNOLOGY 238 XT CE/MPGE is not only raw power, it is also intelligence that supports the welder at every stage of the job. The integrated Arc Force, Hot Start and Anti-Stick functions work together to make MMA welding easier, more efficient and consistent in producing high quality beads.
Hot Start makes arc striking easier by delivering a burst of higher current right at the start of the weld. It removes the problem of the electrode sticking, above all on cold material or with difficult electrodes. Arc Force (arc dynamics) adjusts the welding current according to arc length. When the arc shortens and a short circuit is likely, the current rises, which stops the electrode from sticking and the arc from going out. That allows smooth welding even in awkward positions. Anti-Stick in turn cuts the current to a minimum when the electrode does stick, so you can free it easily without damage or overheating. For the welder this means more control, less frustration and beads with a clean appearance and sound strength.
Versatile Workhorse: Full MMA Capability and TIG LIFT Precision
TELWIN TECHNOLOGY 238 XT is a genuinely versatile tool that meets varied welding tasks. The core process is MMA welding with coated electrodes, where the machine handles rutile, basic, stainless steel and cast iron electrodes with diameters from 1.6 mm up to 5.0 mm. That covers material thicknesses from thin sheet to solid structures.
The welder also offers TIG welding with LIFT ARC contact striking. With a suitable TIG torch with a gas valve connected (available separately), you can produce very clean and precise beads on stainless steel, carbon steel, copper, nickel, titanium and their alloys. The TIG LIFT function keeps tungsten out of the weld pool. This dual capability makes the TECHNOLOGY 238 XT a sound choice for workshops and professionals who need one reliable machine for many applications, from structural and repair work to finer tasks that call for a neat bead.
Mobility and the Tough "XT" Build for Demanding Professionals
Professional welding often takes place in difficult, quickly changing conditions. TELWIN TECHNOLOGY 238 XT was designed for mobility and durability. A low weight of only 6.8 kg and compact dimensions make it easy to transport and handle on a building site, in the workshop or during installation work at height. A solid, ergonomic handle makes carrying easier still.
The "XT" in the model name is not accidental. It points to a reinforced build (eXtreme Toughness), prepared for heavy use and resistant to accidental knocks or harsh surroundings. The IP23 protection rating covers solid bodies and splashing water. All of this translates into a long service life and reliability of the machine even under daily, intensive use. For a professional it means less risk of downtime and confidence that the equipment will not fail at a critical moment.
Technical Specification
| Parameter | Value |
|---|---|
| Key parameters of the TELWIN TECHNOLOGY 238 XT CE/MPGE welder | |
| Catalogue number | 816228 |
| EAN code | 8056590374030 |
| Single phase supply | 230 V - 50/60 Hz |
| Maximum input current | 36 A |
| Maximum input power | 5.5 kW |
| Input power at 60% duty cycle (P 60%) | 3.5 kW |
| Minimum generator power | 8 kW |
| Mains fuse | 16 A |
| Power factor (cosphi) | 0.7 |
| Efficiency | 86% |
| Max open circuit voltage | 75 V |
| Welding current range (MMA) | 20 - 200 A |
| Welding current range (TIG LIFT) | 5 - 200 A |
| Current at 60% duty cycle (MMA @ 40°C, EN60974-1) | 140 A |
| Maximum current (MMA @ 40°C, EN60974-1) | 200 A @ 35% |
| Current at 60% duty cycle (TIG @ 40°C, EN60974-1) | 140 A |
| Maximum current (TIG @ 40°C, EN60974-1) | 200 A @ 35% |
| Coated electrode diameter (MMA) | 1.6 - 5.0 mm (rutile, basic, stainless, cast iron) |
| Protection rating | IP23 |
| Dimensions (L x W x H) | 385 x 150 x 300 mm |
| Machine weight | 6.8 kg |
Key Features and Benefits
- Advanced Inverter Technology: At the heart of the welder is a modern inverter circuit that delivers a stable, precisely controlled welding current. The result is excellent bead quality, less spatter and the ability to weld a broad set of materials. For a professional this means higher efficiency, less finishing work and repeatable results even over long sessions.
- MPGE System (Multi Protection for MotorGenerator): A Telwin technology that fully protects the welder when it runs from a generator. The system compensates voltage fluctuations and shields the electronics against surges. That is complete certainty of operation in typical workshop site conditions, no risk of damaging the equipment and the option to work where stable mains power is not available, which widens mobility and the scope of applications considerably.
- Dynamic Arc Control (Arc Force, Hot Start, Anti-Stick): These three smart functions change MMA welding for the better. Hot Start eases arc striking by briefly raising the current at the start. Arc Force adjusts the welding current automatically, keeping the arc stable and stopping it from going out, even with difficult electrodes or uneven surfaces. Anti-Stick stops the electrode from sticking to the material. For the welder that means easier work, fewer wasted electrodes and better beads regardless of skill level.
- Two Welding Processes: MMA and TIG LIFT: The machine offers efficient coated electrode welding (MMA) with all common electrode types (rutile, basic, stainless, cast iron), and also precise TIG LIFT welding (striking by scratch) of stainless steel, copper or titanium. That flexibility lets you carry out varied projects with a single machine, from heavy structures to precise details.
- Strong Power and a High Duty Cycle: With welding current up to 200A and a duty cycle of 140A at 60% (at 40°C), the TECHNOLOGY 238 XT handles electrodes up to 5.0 mm in diameter and welds thicker material. The high duty cycle keeps the work going without the risk of overheating, which matters on long and demanding tasks and translates into higher productivity.
- Compact "XT" Build and Mobility: Despite its power, the welder is surprisingly light (6.8 kg) and compact. The "XT" marking points to a reinforced build, ready for hard work in the field. Easy transport and storage is a real advantage for mobile service teams, fitters and hobbyists who value order in the workshop.
- High Resistance to Working Conditions (IP23): The IP23 rating means the machine is protected against access to hazardous parts with a wire, against splashing water falling at any angle up to 60° from vertical on every side, and against solid bodies 12.5 mm in diameter and larger. That is a guarantee of safe and reliable work even in less favourable weather or a dusty environment.
Product Applications
- Assembly and installation work in the field (for example steel structures, railings, fences)
- Maintenance and repairs in industrial plants, plant upkeep
- Construction (for example rebar, small welding jobs on site)
- Metalwork, mechanical and automotive workshops (repairs, modifications)
- Small shipyard jobs and repairs of watercraft
- Welding of pipelines and installations (MMA and TIG LIFT)
- Agriculture (repairs of farm machinery and equipment)
- Welding of carbon and low alloy steels, stainless steels, cast iron
- Precise TIG LIFT welding of stainless steel, copper and titanium parts
Summary: TELWIN TECHNOLOGY 238 XT CE/MPGE 230V - Your Best Investment
TELWIN TECHNOLOGY 238 XT CE/MPGE is not only a welder, it is your partner in the pursuit of welding perfection. With 200A of power, the dependable MPGE system for generator work and smart functions that support the welder, you get a tool ready for any task. Its versatility (MMA and TIG LIFT), mobility and tough "XT" build make it a sound choice for professionals and ambitious hobbyists who value top quality and reliability.
Do not let equipment limits hold back your potential. Choose the TELWIN TECHNOLOGY 238 XT and see the difference that Italian engineering and a passion for welding make. Invest in your efficiency and raise the standard of your work today.
Catalogue number: 816228
EAN code: 8056590374030
