Thermanit GE-316L Si, voestalpine Böhler Welding

Thermanit GE-316L Si solid MIG/MAG wire: Böhler Welding wire on a BS300 spool, uncoppered

Thermanit, solid MIG/MAG wire, stainless and acid-resistant steels

Thermanit GE-316L Si solid MIG/MAG wire

EN ISO classification	14343-A G 19 12 3 L Si
AWS classification	A5.9 / SFA-5.9 ER316LSi
Shielding gas	M12: Ar with CO2 added (up to 5 %), M13: Ar with O2 added (up to 3 %)
Approvals	TÜV (00489), DB (43.132.10), DNV, ABS, BV, LR (spec. List), CE

Price on request

Give us the diameter and the quantity, we will quote during working hours

Authorised distributorvoestalpine Böhler Welding

Courier shippingfrom the warehouse in Krotoszyn

Data sheetcomposition, properties, specifications

Wire selectionhelp from a welding engineer

Manufacturer data sheet

Application Specifications Manufacturer datasheet Fits Substitute Bought together

Application

What Thermanit GE-316L Si solid MIG/MAG wire is used for

Thermanit GE-316L Si is a high-alloyed austenitic stainless solid wire. It works on pressure vessels, process piping and austenitic structures where corrosion resistance counts.

Among the parent materials it covers 1.4401, 1.4404, 1.4409, 1.4429, 1.4432, 1.4435 and 1.4436. The wire also suits cladding runs on steel, and the deposit has an austenitic structure.

Classification EN ISO: 14343-A G 19 12 3 L Si
AWS classification: A5.9 / SFA-5.9 ER316LSi
Shielding gas: M12, M13
Diameters: 0.8 / 0.9 / 1.0 / 1.2 / 1.6 / 2.0 mm
Approvals: TÜV (00489), DB (43.132.10), DNV, ABS, BV, LR (spec. List), CE

Keep the heat input down and do not hold the joint hot longer than needed, austenite expands strongly and pulls the structure out of shape. Check the contact tip, a worn bore upsets the wire feed and causes burnback.

Manufacturer datasheet

Chemical composition and properties from the manufacturer datasheet

Datasheet PDF

Typical weld metal values from the voestalpine Böhler Welding data sheet, issue 02/2025. The minimum or the range guaranteed by the maker is given in brackets. The figures depend on the heat treatment condition and the shielding gas stated in the row and do not replace testing the joint to your own WPS.

Chemical composition, wt.-%

	C	Si	Mn	Cr	Ni	Mo
	0,02	0,8	1,7	18,4	12,4	2,8

Welding data and approvals

Polarity	direct current, electrode positive (DC+)
Shielding gas to EN ISO 14175	M11, M12, M13
Heat input	max. 2,0 kJ/mm
Interpass temperature	max. 150 °C
Maximum service temperature	400 °C
Service at low temperatures	down to -196 °C
Heat treatment after welding	usually not needed; if required, solution annealing at 1050 °C and cooling in water
Shielding gas per data sheet	Ar + 2 % CO2, Ar + 2 to 3 % CO2 or Ar + 0 to 5 % H2 + 0 to 5 % CO2
Approvals	TÜV (00489), DB (43.132.10), DNV, ABS, BV, LR, CE
Datasheet edition	02/2025

Mechanical properties of the all-weld metal, typical values

Condition	Yield strength Re, MPa	Tensile strength Rm, MPa	Elongation A, %	Impact energy KV, J at 20 °C	Impact energy KV, J at -196 °C
u	430 (min. 320)	580 (min. 510)	38 (min. 25)	120 (min. 75)	45 (min. 32)

u: Untreated, as-welded, shielding gas Ar + 2.5% CO 2

Fits

For which materials and machines

Base materials

1.4401
1.4404
1.4409
1.4429
1.4432
1.4435
1.4436
1.4571
1.4580
1.4583
UNS S31600
AISI 316L

Process and machines

Solid MIG/MAG wire, works on any sound machine for this process: welders. Shielding gas: M12: Ar with CO2 added (up to 5 %), M13: Ar with O2 added (up to 3 %).

Used welders New welders Ask us to help you choose

Technical substitute

Consumables with the same classification

Same material group, matching classification, a shared diameter and the same shielding gas. Confirm any substitute for your WPS in the documentation.

Spartus

Spartus ER316LSi solid MIG/MAG wire
- ER316LSi
- 0.8 to 1.6 mm
Same classification 14343-A G 19 12 3 L Si, same diameter 0.8, 1.0, 1.2 mm, same gas M12: Ar with CO2 added (up to 5 %)

from 8.89 EURnet
from 10.93 EURgross

Choose a variant
Böhler Welding

BÖHLER Q G 316L-Si solid MIG/MAG wire
- ER316LSi
- 0.8 to 1.6 mm
Same classification 14343-A G 19 12 3 L Si, same diameter 0.8, 1.0, 1.2 mm, same gas M12: Ar with CO2 added (up to 5 %)

from 244.28 EURnet
from 300.47 EURgross

Choose a variant

From the same group

Other consumables for the same material

For comparison before you buy. A technical substitute is listed above.

All: Solid MIG/MAG wires

Böhler Welding priced on request

Thermanit GE-316L Cryo solid MIG/MAG wire
- ER316L
- 1.2 mm
Same classification 19 12, material stainless and acid-resistant steels, same diameter 1.2 mm

Price on request

Ask for a price
Böhler Welding priced on request

Thermanit GE-316L solid MIG/MAG wire
- ER316L
- 0.9 to 1.2 mm
Same group stainless and acid-resistant steels, different class, same diameter 1.0, 1.2 mm

Price on request

Ask for a price
Spartus

Spartus ER316LSi solid MIG/MAG wire
- ER316LSi
- 0.8 to 1.6 mm
Same classification 14343-A G 19 12 3 L Si, material stainless and acid-resistant steels, same diameter 0.8, 1.0, 1.2 mm

from 8.89 EURnet
from 10.93 EURgross

Choose a variant
Böhler Welding

BÖHLER Q G 316L-Si solid MIG/MAG wire
- ER316LSi
- 0.8 to 1.6 mm
Same classification 14343-A G 19 12 3 L Si, material stainless and acid-resistant steels, same diameter 0.8, 1.0, 1.2 mm

from 244.28 EURnet
from 300.47 EURgross

Choose a variant
