Böhler Welding contact tip holder with M8 x 1 thread for the MT 540 W MIG/MAG torch (including the U/D version). It takes M8 contact tips, 30 mm long. Pack of 5.
What it is for
The tip holder connects the contact tip to the torch and carries the current to it. Replace it when the thread is worn and the tip no longer sits firmly, or when the holder is damaged or burnt.
| Part number | 82.16.72931 |
|---|---|
| Brand | Böhler Welding |
| Type | contact tip holder |
| Tip thread | M8 x 1 mm |
| Contact tips | M8, 30 mm long |
| Drawing item no. (price list 2026/27) | 2 (MT 540 W) |
| Replaces part no. | 82.16.56797 |
| Pack quantity | 5 pcs |
Fits
Also order
You can order together with the tip holder:
- Contact tip M8 1.0 mm ECu (10 pcs)
- Contact tip M8 1.0 mm CuCrZr (10 pcs)
- Gas nozzle for MT 540 W (5 pcs)
- Insulating washer for MT 440 W, MT 540 W (10 pcs)
FAQ
Which contact tips fit this holder?
M8 x 1 tips, 30 mm long: ECu 0.8 to 1.2 mm, CuCrZr 0.8 to 1.6 mm and ECu for aluminium wire 0.8 to 1.6 mm. Example for 1.0 mm wire: ECu M8 1.0 mm or CuCrZr M8 1.0 mm.
Does the MT 540 W holder fit other MT torches?
The Böhler price list gives a separate holder for each torch. Order the one listed for your model; holders for the others: MT 350 G and MT 440 W.
I am looking for part no. 82.16.56797. Is this the right part?
Yes. According to the manufacturer, 82.16.72931 replaces 82.16.56797.
