The RC 100 MP is a Böhler Welding remote control with digital CAN bus communication. According to the Böhler selection guide it has the same functions as the RC 100: welding current adjustment, digital LED display, current and voltage reading. In the price list 2026/27 it has one part number without a cable length, and the 6, 10 and 25 m CAN bus cables are listed next to it as separate items.
What it is for
Choose the RC 100 MP when you want to pick the cable length separately from the remote. The cable is a separate item, so if it gets damaged you order only the cable. The magnetic hanging device lets you attach the remote to a steel part next to the joint.
| Part number | 71.02.209 |
|---|---|
| Brand | Böhler Welding |
| Model | RC 100 MP |
| Type | remote control |
| Communication | digital, CAN bus |
| Cable length | ordered separately (CAN bus cable 6, 10 or 25 m) |
| Dimensions | 130 x 85 x 60 mm |
| Weight | 0.7 kg |
| Functions | welding current adjustment, digital parameter adjustment, digital display of welding parameters, current reading, voltage reading |
| Display | 7-segment LED |
| Mounting | magnetic hanging device |
| Pack quantity | 1 pc |
Fits
According to the Böhler price list 2026/27:
- MMA: TERRA 270/350 RC, TERRA 500 RC
- MIG/MAG: TERRA NX 320/400 SMC, TERRA NX 400/500 MSE
- pulsed MIG/MAG: TERRA NX 320 PME, TERRA NX 320/400 PMC, TERRA NX 400 PMC DualFeeder, TERRA NX 400/500 PME, URANOS NX 2200 PMC, URANOS NX 2700 PMC
- multi-process: URANOS NX 2200 MTE, URANOS NX 2700 MTE, URANOS NX 3200 GSM, URANOS NX 4000/5000 GSM
- TIG DC: TERRA NX 270 TLH, TERRA NX 320/400 TLH, URANOS NX 2200 TLH
- TIG AC/DC: URANOS NX 2200 AC/DC, URANOS NX 2700/3200 AC/DC, URANOS NX 4000/5000 AC/DC
Also order
CAN bus connection cable: 6 m (71.02.20501), 10 m (71.02.205) and 25 m (71.02.20504). The price list does not name the 6 m cable for TERRA NX SMC, PMC, PMC DualFeeder, MSE and 400/500 PME; choose 10 or 25 m there.
FAQ
Is a cable included with the RC 100 MP?
In the Böhler price list the RC 100 MP has one part number without a length, and the 6, 10 and 25 m CAN bus cables are separate items in the same block. Order the cable together with the remote.
What is the difference between RC 100 MP and RC 100?
According to the price list, functions, dimensions and weight are the same. The RC 100 comes with a 6, 10, 25 or 40 m cable under one part number, while for the RC 100 MP you choose the cable separately.
Does the RC 100 MP adjust voltage?
No, in the selection guide it only adjusts current. The RC 200 has voltage adjustment.
We order this item from the manufacturer for you. Spawlab is an authorised Böhler Welding distributor and service partner in Poland: VAT invoice, shipping from Krotoszyn, also to EU countries.
