The small hip belt is the padded hip belt in size S, with lugs for attaching a shoulder harness. It comes with the Supplied Air compressed air regulator, and the newer Guardian Air manual (2025) also lists it as the belt for that unit.
Technical specifications
| Catalogue number | 76992 |
|---|---|
| Brand | Böhler Welding |
| Compatible with | Supplied Air (57038), Guardian Air |
| Type | small padded hip belt (S) |
| Waist size | 60 to 150 cm (Supplied Air manual) |
| Material | textile: polyester, EVA, PC |
| Harness | lugs for 57146 |
| Pack quantity | 1 pc |
Who it is for
For Supplied Air and Guardian Air users who replace a worn belt. The Supplied Air regulator itself weighs 475 g without belt.
Key features
- Padded belt, narrower than the standard one.
- Lugs for attaching the 57146 shoulder harness.
- Waist size 60 to 150 cm according to the Supplied Air manual.
- Textile part made of polyester, EVA and PC.
- Optional 64255 extension adds 265 mm.
Fitting and adjusting the small hip belt
To fit the unit, pass the inner strap through the rear loops of the unit, then through the two belt loops and the buckle. Fasten the belt around your waist with the unit at the back and adjust it with the sliding adjuster; tuck excess belt into the loops.
Compatible with
The Supplied Air regulator, the Guardian Air unit and the kits built on it:
- Böhler Welding Supplied Air compressed air regulator for air-fed helmets, complete kit
- Böhler Welding Guardian Air PAPR blower unit, complete kit with filter
- Böhler Welding Guardian Air motor unit with filter cover, PAPR blower without filters
- Böhler Welding Guardian 50M Air Kit, welding helmet with Guardian Air PAPR
- Böhler Welding Guardian 50FM Air Kit, flip-up welding helmet with Guardian Air PAPR
- Böhler Welding Big Vision Air Kit Guardian Air, grinding visor with Guardian Air PAPR
Consumables and spare parts
- Böhler Welding hip belt extension 265 mm PAPR, Supplied Air
- Böhler Welding PAPR shoulder harness Evolution Air, Guardian Air, Supplied Air
- Böhler Welding nuisance filter with sealing ring Supplied Air
- Böhler Welding ball rotameter, airflow tester for PAPR and Supplied Air
All PAPR parts: Filters and powered air parts.
Documents
- Supplied Air instruction manual (PDF, multilingual)
- Guardian Air instruction manual (PDF, multilingual)
- Supplied Air specification with spare parts (PDF, English)
- PPE & accessories catalogue 2023/24 (PDF, English)
Frequently asked questions
What waist size does it fit?
The Supplied Air manual gives 60 to 150 cm. The Böhler Welding hip belt extension 265 mm PAPR, Supplied Air adds 265 mm.
Can I attach a shoulder harness?
Yes, the belt has lugs for the Böhler Welding PAPR shoulder harness Evolution Air, Guardian Air, Supplied Air.
Does it fit Evolution Air?
The Evolution Air manual lists the standard 57144 belt and the leather 75685 belt, not the small one.
