Böhler Welding PAPR quick charger for the quick-charge battery Evolution Air, Guardian Air

The PAPR quick charger is the charger for the 87598 heavy-duty 7800 mAh quick-charge battery used in Evolution Air and Guardian Air. The Evolution Air manual makes two points: battery 87598 requires this charger, and the charger is for that battery only.

Technical specifications

Who it is for

For users of battery 87598, for example from the Evolution Vision 65F Air Kit and 65FM Air Kit, who want a second charger or replace a damaged one. It works indoors only: 0 to +25 °C and humidity below 65 %.

Key features

• Input 100 to 240 V, 50/60 Hz, output 8.4 V, rated current 1500 mA.
• For battery 87598 only (Li-Ion 7.4 V, 7800 mAh).
• For Li-Ion packs only, with short-circuit protection.
• Interchangeable plug adapter for different mains.
• Red LED: charging; green LED: battery charged.

How to charge with the PAPR quick charger

First connect the plug to the battery, then the charger to the mains. The charger and battery may warm up to 50 °C; if hotter, stop charging. When finished, unplug the charger from the mains first, then disconnect the plug. Do not charge other batteries and do not open the housing; repairs are done by the manufacturer.

Quick or universal charger

The 57081 universal charger charges batteries 57075 (8 to 9 h) and 86660 (4 to 6 h) and works up to +40 °C. The universal charger will not charge battery 87598, and the quick charger will not charge batteries 57075 and 86660.

Compatible with

The quick-charge battery and the Evolution Air and Guardian Air units and kits it works in:

• Böhler Welding heavy-duty quick-charge battery 7800 mAh Evolution Air, Guardian Air
• Böhler Welding Evolution Air PAPR blower unit, complete kit with filters
• Böhler Welding Evolution Air motor unit, PAPR blower without filters
• Böhler Welding Guardian Air PAPR blower unit, complete kit with filter
• Böhler Welding Guardian Air motor unit with filter cover, PAPR blower without filters
• Böhler Welding Guardian 62 Air Kit, welding helmet with Evolution Air PAPR
• Böhler Welding Guardian 62F Air Kit, flip-up welding helmet with Evolution Air PAPR
• Böhler Welding Guardian 50M Air Kit, welding helmet with Guardian Air PAPR
• Böhler Welding Guardian 50FM Air Kit, flip-up welding helmet with Guardian Air PAPR
• Böhler Welding Evolution Vision 65F Air Kit, flip-up welding helmet with Evolution Air PAPR
• Böhler Welding Evolution Vision 65FM Air Kit, auto-shade welding helmet with Evolution Air PAPR
• Böhler Welding Evolution V80 Air Kit, welding helmet with Evolution Air PAPR
• Böhler Welding Evolution V80M Air Kit, auto-shade welding helmet with Evolution Air PAPR
• Böhler Welding Big Vision Air Kit Guardian Air, grinding visor with Guardian Air PAPR
• Böhler Welding Big Vision Air Kit Evolution Air, grinding visor with Evolution Air PAPR

Consumables and spare parts

• Böhler Welding universal PAPR charger Evolution Air, Guardian Air
• Böhler Welding heavy-duty battery 7800 mAh Evolution Air, Guardian Air
• Böhler Welding P R SL particle filter Evolution Air (4 pcs)

All PAPR parts: Filters and powered air parts.

Documents

• Quick charger manual (PDF, multilingual)
• Evolution Air instruction manual (PDF, multilingual)
• Evolution V80 Air Kit fact sheet with Evolution Air spare parts (PDF, English)
• PPE & accessories catalogue 2023/24 (PDF, English)

Frequently asked questions

Can I charge battery 57075 or 86660 with it?

No. The manual restricts this charger to battery 87598. Charge batteries 57075 and 86660 with the Böhler Welding universal PAPR charger Evolution Air, Guardian Air.

How do I know the battery is charged?

The red LED is on while charging, and the green one lights up when the battery is charged.

Why must the charger not stand in a warm place?

The manual allows operation only at 0 to +25 °C and humidity below 65 %.
